Braccio porta TV Orientabile
Staffa TV Motorizzata da parete Ulisse 1000 (aperta)
Staffa TV Motorizzata da parete Ulisse 1000 (chiusa)

Ultimate 1000

The motorized TV bracket Ultimate 1000 is designed to be installed inside a wall recess or within a paneling. Ultimate 1000 motorized TV brackets allow you to push the television forward and open it like a book up to 90 degrees with extraordinary smoothness.

ā¤ļø We are here to help you create a custom solution for your needs. Does your product doesn't fir in our current standard dimensions? Ask us for a quote and you'll see the difference it makes to work with professionals. We guarantee the safety of measurements and products compliant with legal regulations.

Request a Quote
Category: Product ID: 22169

Description

Motorized Wall TV Bracket

The motorized TV arm is powered by a powerful low-voltage electric pistonĀ controlled by an encoder. Ultimate 1000 can be mounted with the opening to the rightor left, ideal for TVs up to 65 inches. The TV screen is fixed and positioned usingĀ VESA 300 – 400 mounting holes and attachments.

The TV cables can be neatly managed inside a special openable channel. The motorized TV support Ultimate 1000 is operated by a small two-channel remote control provided, alternatively, it can be connected to home automation through clean contacts present inside the control unit.

Accessories

  • Stabilized power supply 110/240V – 50/60 Hz
  • 2-channel remote control

Optional accessories:

  • Motorized opening/closing device for the door capable of
    retracting inside the furniture before the television starts to rise.
  • Anti-collision and anti-cutting sensitive edge
braccio porta tv coppia

FAQ

The motorized TV bracket Ultimate 1000 is designed to be installed inside a wall recess
or within a boiserie, offering a discreet and elegant mounting solution for your TV.

The TV arm of the Ultimate 1000 is driven by a powerful low-voltage electric piston controlled by an encoder.
This allows the TV to be pushed forward and opened up to 90 degrees with extraordinary smoothness. The support can be operated via a small two-channel remote control provided, or it can be connected to a home automation system for integrated management.

The Ultimate 1000 is equipped with optional sensitive edges which, in case of impact or crushing,
immediately stop and reverse the movement of the mechanism, allowing the obstacle to be removed. Additionally, an electronic device can be activated to raise the mechanism when the TV is turned on and lower it when it is turned off, providing an extra layer of security.

The Ultimate 1000 features an openable channel where the TV cables can be neatly managed. This provides an efficient and tidy solution for cable management, keeping the TV installation area clean and clutter-free.

Safe and reliable control of the retractable TV system

The electronic control unit, the heart of the entire system, monitors and managesĀ all functions of the mechanism, including all safety devices. Optional sensitive edges, mounted directly in the furniture, will stop and immediately reverse the motion in case of impact or crushing, allowing the obstacle to be removed.

Ultimate 1000 is meticulously handcrafted in our company.

Ultimate 1000 is manufactured at very low voltage (24Vdc), CE certified at the GSD laboratory in Pisa.
